Cambium Networks 4.9 to 6.05GHz PTP 650 Connectorized AC Supply (FCC/IC)
The PTP 650 Connectorized END operates in the expanded 4.9 to 6.02 GHz license exempt radio frequencys. Channel size is configurable between 5, 10, 15, 20, 30, 40 and 45 MHz channels sizes depending on individual country regulations. Device ships as a lite model with up to 125 Mbps of available user data throughput. With optional upgrades, throughput can be increased to up to 450 Mbps. Connectorized model can operate with a selection of seperately-purchased single- and dual- polarity antennas through 2 x N-type female connectors. AC Power Supply is included.
With Dynamic Spectrum Optimization (DSO), PTP 650 systems are constantly optimizing the channel of operation to maximize link reliability and performance. The systems can provide up to 99.999% availability in virtually any environment, including non-line-of-sight, long-distance line-of-sight, high interference, over water and desert, and through extreme weather conditions. As a result, you can deliver more throughput with less spectrum and less investment in even the most challenging environments.
Whether your organization is an enterprise, government agency, or service provider, PTP 650 systems are ideal solutions for a wide array of applications such as T1/E1 and fiber replacements or extensions; video surveillance backhaul; LTE, macro-cell, and small-cell backhaul; last-mile access; disaster recovery; network redundancy; and building-to-building campus connectivity.
Cambium Networks disrupts the performance-reliability continuum with the Cambium Point-to-Point (PTP) 650 Series solution. With up to 450 Mbps aggregate throughput, PTP 650 systems let you reliably and securely handle today’s needs with scalability to meet future requirements.
Service providers, government public safety agencies, and critical infrastructure operators such as utilities and energy companies have experienced massive growth in data, voice, and video traffic over the past few years. This growth has imposed large bandwidth demands for reliable and secure broadband connectivity and backhaul worldwide.
Frequency Band 4.9GHz to 6.06GHz
Ethernet Capacity Up to 450Mbps
TDM Capacity NA
Radio Type IP
Description PTP 650 Connectorized END with AC Supply (FCC/IC)
System Configuration All Outdoor
Modulation 5, 10, 15, 20, 30, 40, and 45 MHz channels
Temperature Range -40 to 60C
